MT7601BE is a high current precision linear LED driver. The output constant current is programmable by an external resistor.

MT7601BE integrates high voltage power MOSFET and high voltage power supply circuit, the peripheral circuit is simplified. It can easily pass EMI without inductor, transformer or other magnetic components, low BOM cost is achieved.

MT7601BE is designed with thermal regulation function to balance the output power and system temperature. The output current will be reduced while the junction temperature goes higher than the threshold, system reliability is guaranteed.

• Few external components, low BOM cost

• Integrated with 700V power MOSFET

• LED current set by external resistor

• Constant current precision: ±5%

• Low EMI interference

• Embedded thermal regulation function

• Available in ESOP8 package
