MT7606S is a high current precision linear LED driver. The output constant current is programmable by an external resistor.

MT7606S integrates high voltage power MOSFET and high voltage power supply circuit, which simplifies the peripheral circuit. It can easily pass EMI without inductor, transformer or other magnetic components, low BOM cost is achieved.

The chip integrates thermal regulation function to balance the output power and system temperature. The output current will be reduced while the junction temperature goes higher than the threshold, system reliability is guaranteed.

• Few external components, low BOM cost

• Integrated with 500V power MOSFET

• LED current set by external resistor

• Constant current precision: ±5%

• Low EMI interference

• Embedded with thermal regulation function

• Available in SOT89-3 and ESOP8 package
