MT7641F
-
DESCRIPTION
MT7641F is a controller for removing LED 100/120Hz current ripple. It achieves no flick output through the internal low-pass filter, which can remove the low frequency current ripple.
MT7641F integrates startup circuit to shorten the time of reaching a stable state. Multiple MT7641F can be connected in parallel to realize a higher output current.
MT7641F is available in SOT23-3 package, especially suitable for small size lamps.
-
FEATURES
Low-pass filter to remove current ripple
Quick start
Multiple chips connected in parallel to increase output current
Available in SOT23-3 package
Expand All
APPLICATIONS
-
No flicker LED lighting applications
