  • DESCRIPTION

    MT7282 is a constant current white LED driver IC designed for wide input voltage range from 2.5V to 40V system rail. The chip can be configured as Buck, Boost and Buck-Boost topology. The chip can drive up to 10W with AC12V/DC12V input voltage. Current mode and fixed frequency operation provides fast transient response and eases loop stabilization. With a current sense amplifier threshold of 200mV, the LED current is programmable with one external current sense resistor and the power loss is minimized. The 415kHz operating frequency minimizes external inductor, input and output capacitor.

    MT7282 supports both PWM and analog dimming by a single control pin. The chip is integrated with fault condition protection includes over-voltage protection (OVP), cycle-by-cycle peak current limiting and thermal shutdown.

    MT7282 is available in ESOP8 package.

  • FEATURES
    • Input/output voltage range: 2.5V to 40V input/output voltage range

    • High efficiency up to 95%

    • Cycle-by-cycle over current protection

    • Internal 0.2Ω power MOS

    • Supports Boost, Buck-Boost, Buck topology

    • LED temperature protection

    • Stable with Low ESR Ceramic Capacitor

    • OTP and OVP protection

    • External setting over-voltage protection

    • Fixed switching frequency: 415kHz

    • Frequency jittering for reduced EMI

    • Low feedback voltage: 200mV

    • Adjustable soft-start

    • Support one pin analog dimming and up to 10kHz PWM dimming

    • Available in ESOP8 package

APPLICATIONS
  • Automotive and Marine Lighting

  • High Power LED Driver

  • Torch Driver

  • Low voltage LED Lighting (Landscape, Desk, Room, MR16 lighting)

  • LED backlighting

  • dianlutu1400636pxMT7282.jpg
